SOFTWARE LAB - 1
Overview
This subject focuses on the fundamentals of engineering graphics and technology. Since drawing is the language of communication for engineers and has application in all branches of engineering, Students of all branches have to undergo this course. Design drawings allow viewers to visualize a machine or its components before it is manufactured. In the current industrial trend CAD modelling is an imperative skill expected from all Mechanical engineers. Students practice the development of 3D drawings of machine components and perform virtual assembly using industry leading mechanical design software Solid Edge. Solid Edge modelling and assembly tools enable students to easily develop a full range of products, from single parts to assemblies containing thousands of components with accurate fit and modify them within the assembly model. The lab is equipped with 66 numbers of high end computer systems
Laboratory Area: 235 Sq. Mts
Laboratory Expenditure: Rs. 3032048.00
Major Equipments
| Equipment Name | Specifications |
|---|---|
| Solid Edge Classic ST7 ACADEMIC LICENSE UPGRADED TO ST8 | Siemens Solid EDGE ST8 Drafting Software |
| Solid Edge Classic ST7 ACADEMIC LICENSE bundle software ME & S | Solid Edge ST7 ACADEMIC bundle software ME & S |
| Acer desktop Veriton M200 from Emdees | Core i3 Processor, 4GB DDR3 RAM, 1GB Dedicated Graphics Card, Optical USB Keyboard, Mouse, 18.5" Monitor, 500 Gb HDD |
| Acer desktop Veriton M200 from BS InfoTech | Core i3 Processor, 4GB DDR3 RAM, Optical USB Keyboard, Mouse, 18.5" Monitor, 500 Gb HDD, with windows 8.1 OS |
| Windows 8.1 operating System Licensed | windows 8.1 |
| Numeric 20 KVA ups with 26AH SMF Quanta battery 20 No's | 20 KVA with 20 Batteries with Stand |
| Canon all in one printer MF 3010B | ALL in One MF3010 |
| Canon laser printer LB 2900 | LB 2900 |
| LCD Projector with Screen | EPSON EB X31 |
| External DVD Writer LG MAKE | DVD writer |
| DJA amplifiers, air 6 mixing consoles, E900 dual system wireless microphone circle | 6 Air mixing consoles with a range of 80 ft |
| Stone water ceiling fitted speakers | Ceiling Speakers |
| Toshiba external hard disk (1TB) | 1 TB |
Laboratory Layout
Photos
